| 项目 general information | 单位unit | 600 | 2500 | 3000 | 5000 | |||||||
| 机器型号 Model | G600-6 | G600-9 | G2500-4 | G2500-6 | G3000-3 | G3000-5 | G5000-4 | |||||
| 模穴数 cavity number | pcs | 6 | 9 | 4 | 6 | 4 | 6 | 4 | ||||
| 最大螺牙尺寸 max thread size | mm | 30 | 30 | 40 | 40 | 40 | 40 | 50 | ||||
| 最大瓶子直径 max.container diameter | mm | 70 | 70 | 110 | 110 | 135 | 135 | 175 | ||||
| 最大瓶子高度 max.container height | mm | 430 | 430 | 430 | 430 | 430 | 430 | 430 | ||||
| 理论产量 theoretical yield | bph | 12000(600ml) | 16000(600ml) | 7200(600ml) | 11000(600ml) | 6000(600ml) | 10000(600ml) | 3600 | ||||
| 装机功率 total power | kw | 104 | 120 | 124 | 144 | 124 | 144 | 280 | ||||
| 实际使用功率 the actual use of power | kw | 35-40 | 50-55 | 30-35 | 45-50 | 30-35 | 45-50 | 50-60 | ||||
| 外型尺寸 appearance size | m | 4.8*1.85*2.6(2.4) | 6.3*1.85*2.6(2.4) | 4.8*1.85*2.6(2.4) | 6.3*1.85*2.6(2.4) | 4.8*1.85*2.6(2.4) | 6.3*1.85*2.6(2.4) | 8*2.1*2.6(2.4) | ||||
| 重量 weigh | kg | 5500 | 7000 | 5500 | 7000 | 5500 | 7000 | 12000 | ||||
| 外型尺寸 appearance size | m | 2.8*2*3 | 2.8*2*3 | 2.8*1.6*2.8 | 2.8*2*3 | 2.8*1.6*2.8 | 2.8*2*3 | 2.8*1.6*2.8 | ||||
| 重量 weigh | kg | 400 | 400 | 400 | 400 | 400 | 400 | 400 | ||||
| 工作压力 working pressure | bar | 9 | 9 | 9 | 9 | 9 | 9 | 9 | ||||
| 低压耗气量 low air consumption | m3/min | 2 | 3 | 2 | 3 | 2 | 3 | 3 | ||||
| 吹瓶压力 blowing pressure | bar | 30 | 30 | 30 | 30 | 30 | 30 | 30 | ||||
| 高压耗气量 high air consumption | m3/min | 10 | 12 | 8 | 10 | 8 | 10 | 16 | ||||
| 温度范围 temperature range | ℃ | 10 | 10 | 10 | 10 | 10 | 10 | 10 | ||||
| 规格 Model | HP | 10 | 12 | 8 | 10 | 8 | 10 | 16 | ||||
| 伺服转盘 servo pushing | ● | ● | ● | ● | ● | ● | ● | |||||
| 伺服拉伸 servo stretching | ● | ● | ● | ● | ● | ● | ● | |||||
| 伺服合模 servo clamping | ●● | ●● | ●● | ●● | ●● | ●● | ●● | |||||
| 伺服分坯 servo preform loading | ● | ● | ● | ● | ● | ● | ● | |||||
| 伺服移坯 servo moveing | ● | ● | ● | ● | ● | ● | ● | |||||
| 高压补偿锁模 compensation plate mould | ● | ● | ● | ● | ● | ● | ● | |||||
| 变频温控 Variable frequency temperature | ● | ● | ● | ● | ● | ● | ● | |||||
| 模腔中心距 mould center distance | mm | 80 | 80 | 120 | 120 | 160 | 160 | 200 | ||||
| 开模行程 the opening stroke | mm | 150 | 150 | 150 | 150 | 160 | 160 | 200 | ||||
| 模具厚度 mold thickness | mm | 220 | 220 | 220 | 220 | 220 | 220 | 280 | ||||
| 最大杆径 | mm | 14 | 14 | 14 | 14 | 14 | 14 | 20 | ||||
| 坯头数（总/烘/次） | pcs | 156/80/13.3 | 194/112/12.4 | 125/68/17 | 155/90/15 | 125/68/17 | 155/90/15 | |||||
| 灯管规格(长度/功率) | 800L/2500W[扁头] | 1100L/3000W[扁头] | 800L/2500W[扁头] | 1100L/3000W[扁头] | 800L/2500W[扁头] | 1100L/3000W[扁头] | ||||||
| 烘箱规格([组数]*层数) | [4]*8 | [4]*8 | [4]*10 | [4]*10 | [4]*10 | [4]*10 | [8]*10 | |||||
| 加热中心距40 | 加热中心距40 | 加热中心距50 | 加热中心距50 | 加热中心距50 | 加热中心距50 | 加热中心距60 | ||||||
台州市黄岩业康机械有限公司，秉承了二十多年的吹瓶机制造经验。
